INPUT: 1 s-Video: 1Vpp/75Ω (Y), 0.3Vpp/75Ω (C), on a 4-pin connector.
OUTPUTS: 5 s-Video: 1Vpp/75Ω (Y), 0.3Vpp/75Ω (C), on 4-pin connectors.
MAX. VIDEO OUTPUT: 2Vpp (Y).
VIDEO BANDWIDTH (-3dB): 230MHz (Y).
DIFF. GAIN: 0.08%.
DIFF. PHASE: 0.12Deg.
K-FACTOR: <0.05%.
S/N RATIO: 72dB.
COUPLING: AC.
POWER SOURCE: 12V DC, 100mA.
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H.
WEIGHT: 0.28kg (0.62lbs) approx.
ACCESSORIES: Power supply, mounting bracket.
OPTIONS: RK-3T 19" rack adapter.
